Valve Parts

Ball Valves

Ball Valves

Sanitary ball valves, whether manually or automatically actuated, are used mainly with viscous fluids containing solid particles, and, generally, in applications requiring an unobstructed flow.
The ball valve can be operated automatically with a ball valve actuator or manually with a handle.

Suitable for the food-processing, beverage, wine-making, oil-making, cosmetic and chemical industries.

The handle blocks the valve in the "open" or "closed" position. The actuator transforms the axial movement of the piston into a 90ยบ rotary movement which it transmits to the ball.

Download file
Design and features

Compact and robust design.
Available in sizes DN 25/1" to DN 100/4".
Two-position handle.
Easily interchangeable manual handles and pneumatic or electrical actuators.
Low pressure losses.
Half-bodies exchangeable with any connection type.
DIN 11851 connections.
Marking of seals allows traceability.

Options

Valve in AISI 304.
Seals in NBR, VMQ or FPM.
All of them according to FDA 177.2600
Connections: welding, DIN, Clamp, SMS, RJT, FIL-IDF, etc.
Handle, lever, safety handle with lock,etc.
Single- or double-acting pneumatic actuator
or electrical actuator.
Position sensors (micro-switches or inductive).
C-TOP control head.
Cleaning and drainage connections.
Third hole.

Materials

Ball: AISI 316L / 316
Flanges: AISI 316L / 316 (forged)
Gasket: EPDM according to FDA 177.2600
Handle: AISI 304 / PP
Surface finish: Hygienic polish
